- Pumps feature high mechanical and volumetric efficiency, low noise level.
- End head prepared for lift-hold-lower applications using our standard manual lowering valve or solenoid cartridge valves.
- Totally enclosed motors are suitable for use in humid environments or dusty, contaminated atmospheres.UL Recognized and CSA Certified* AC electric motors feature heavy gauge steel frame and base and high-quality ball bearings.
- Torque load remains constant throughout the range of operation.
- Power up, gravity down function.
- Heavy duty start switches with high IP protection class and silver plated contacts meet tough demands for a long service life.
- Cartridge-style relief valves meet tough demands for dependability and life expectancy.
- Equipped with black plastic and steel reservoirs.
- Vertical mounting
- 3/8 NPT Return Port
- 9/16-18 SAE Pressure and Aux. Pressure Ports
- Equipped with oil level dipstick.
- High performance cartridge check valve is standard.
- Most premium grade petroleum based fluids can be used. Optimum operating viscosity range is 15-68 cSt.;
- Minimum recommended temperature is -25ºC (-13ºF).
- Maximum recommended temperature is+80ºC (+175ºF)
- 12-months warranty
Technical Specifications
SKU: 1801410
3.6 Gal Reservoir, 2,650 PRV, 2.5 HP Motor, 208-230V / 50-60 Hz / 1 Ph, UL/ETL Listed
SKU: 1801472
3.6 Gal Reservoir, 2,850 PRV, 2.5 HP Motor, 208-230V / 50-60 Hz / 1 Ph, UL/ETL Listed
SKU: 1801411
4.2 Gal Reservoir, 2,650 PRV, 2.5 HP Motor, 208-230V / 50-60 Hz / 1 Ph, UL/ETL Listed
