No more guessing, get the power you need! – Complete power control
Air Flex Mini – The patented Air Flex Mini air inlet feature provides freedom of movement and turns any rigid hose into a flexible one, thanks to a multi-axis air connection swivel. Ensures the hose is always in the ideal position and gives easier access to hard-to-reach areas.
The best and the most adjustable power control for pneumatic tools 5, 10, 15, 20, 25, 30, 35, 40, 45, 50 and 100% of maximum torque
Twin hammer mechanism
Bumpers all over the tool
Bi-material and bi-color handle and trigger
Friction ring socket retainer
One hand reverse – New Side2Side system
Composite motor housing
Specifications
Model: CP7755-AFM
Part number: 8941077551
Actual air consumption: 108 l/mn: 3.9 cfm
Air inlet thread size: 1/4 “
Blows per minute: 1200
Working Torque Range (fwd): 80 – 575 Nm / 59 – 425 ft.lbs
Box dimensions: 272x209x95 mm: 10,7×8,2×3,7 “
Clutch type: Twin hammer
Free speed: 7700 rpm
Free speed air consumption: 5.6 cfm
Handle type: Pistol
Height: 7.83 “
Length: 6.65 “
Maximum Torque (fwd): 1080 Nm / 796 ft.lbs
Maximum Torque (reverse): 1300 Nm / 960 ft.lbs
Min. hose size: 10 mm: 3/8 “
Net weight: 1.85 kg: 4.0 lb
Power/weight ratio: 702 Nm/kg / 234 ft.lb/lb
Side to center: 38 mm / 1-1/2 “
Socket retainer: Friction ring
Sound Power: 105 db(A)
Sound pressure: 94 db(A)
Sound uncertainty: 3 db(A)
Square drive: 12.7 mm
Vibration: 8.5 m/s²
Vibration ISO: ISO-28927-2
Vibration uncertainty (K): 3.4 m/s²
Width: 76 mm / 3 “
*Final torque must be applied manually using a calibrated torque wrench
