When you’re serious about your TIG welds on steel, stainless steel, or aluminum, count on the Eastwood TIG 200 AC/DC to get you through your toughest projects. It’s packed with quality features for maximum functionality and uses the latest technologies for performance you can count on.
It starts with dual power cords that plug into either a 120V or 240V outlet, letting you use this 200-Amp welder almost anywhere. Its high-frequency start delivers precise arc control to prevent tungsten contamination and it features square-wave inverter to accurate weld aluminum in addition to both mild and stainless steel up to 1/4-in. thick.
A flex-head WP-17 torch is included for maximum versatility along with a ceramic gas lens kit, a comfortable rocker-style foot pedal, and a flowmeter. An easy-to-read control panel gives you full command of the settings you need without confusing features you won’t use.
Can also stick weld with addition of electrode holder (Eastwood Item # 20517). With a 60% duty cycle, the TIG 200 AC/DC is a workhorse that keeps you welding until the job is finished.
And it’s all backed up by Eastwood’s 3-year warranty and lifetime tech support.
Eastwood TIG 200 AC/DC features:
3 Years
| Input Voltage: | Single-Phase 120vAC or 240vAC @ 50-60Hz |
| Power Cord Receptacle Plug: | NEMA 6-50P |
| Input Current TIG: | 240v: 23.8 amps | 120v: 20.0 amps |
| Input Current Stick: | 240v: 36.2 amps | 120v: 19.2 amps |
| Output Current Adjustment TIG: | 240v: 10-190 amps |. 120v: 10-145 amps |
| Output Current Adjustment Stick: | 240v: 10-185 amps |. 120v: 10-140 amps |
| Input Voltage TIG: | 240v: 10.4v – 17.6v | 120v: 10.4v – 15.8v |
| Input Voltage Stick: | 240v: 20.4v – 27.4v | 120v: 20.4v – 25.6v |
| Starting Methoda: | High Frequency |
| TIG Welding AC Duty Cycle (%): | 240v 60% at 190 amps and 100% at 143 amps | 120v 60% at 100 amps and 100% at 77 amps |
| STICK Welding Duty Cycle (%): | 240v 60% at 185 amps and 100% at 143 amps | 120v 60% at 60 amps and 100% at 46 amps |
| Post Gas Flow: | 2-8 sec. |
| Pre Gas Flow: | 0.1-1.0 sec. |
| Remote Foot Pedal And Control: | Yes |
| Torch Control: | Finger on/off control/Variable foot pedal |
| Cooling Method: | Fan |
| Overall Dimensions: | 17.8-in. x 8.4-in. x 20.20-in. |
| Weight: | 38 lbs. |
Duty Cycle
The Rated Duty Cycle refers to the amount of welding that can be done within an amount of time. The Eastwood TIG 200 has a duty cycle of 60% at 190 Amps. It is easiest to look at your welding time in blocks of 10 Minutes and the Duty Cycle being a percentage of that 10 Minutes. If welding at 190 Amps with a 60% Duty Cycle, within a 10 Minute block of time you can weld for 6 Minutes with 4 Minutes of cooling for the welder. To increase the Duty Cycle you can turn down the Amperage Output control. Going above 190 Amps will yield a lower duty cycle.
