Detects all refrigerant leaks as low as 1/10 oz. per year
“Super Sensitive Function” allows the unit further sensitizing beyond the standard settings for locating small leaks with gases such as R1234yf and R407C
HIGH 0.15 oz/yr (4 g/yr)
MEDIUM 0.25 oz/yr (7 g/yr)
LOW 0.50 oz/yr (14 g/yr)
PROBE:
Intelligent tip design that senses the condition of the environment, to eliminate the potential of false alarms.
Flexible 15.5″ probe for difficult to reach locations
DISPLAY: Six vertical LED’s (red, yellow or green) display the following information to the user such as:
Relative signal level of the detected leak
Selected sensitivity range (low/medium or high) of the unit
Diagnostic information: low battery, interference/wait, contaminated atmosphere, readiness of the unit or fault conditions of the unit
REFRIGERANTS: Detects all refrigerants (CFC’s, HCFC’s, & HFC’s and blends)
SENSOR LIFE: 2000 hours
SENSING ELEMENT: Heated tin oxide
OPERATING TEMPERATURE RANGE: 0 to 140ÀöF
REPSONSE TIME: Less than 1 second
POWER: 2 C Alkaline 6000 mAh batteries
BATTERY LIFE: 30 hours
WEIGHT: 1.08 lbs
KEYPAD FUNCTIONS:
ON/OFF: Press the ON/OFF button to turn the unit on or off
VOLUME/MUTE: Press the VOLUME/MUTE button to control the volume of the unit
H M L SENSITIVITY: Press the H M L SENSITIVITY button to select the desired sensitivity level
PEAK/HR/LR: The PEAK/HR/LR key serves a dual purpose:
To assist the user in locating the “largest leak” in a system with multiple leaks present
To enable the user to switch between HR (high range) and LR (low range) modes
