PCE Instruments Electrical Insulation Tester (PCE-ITE 50) is a robust electrical testing device designed for professional insulation resistance measurements. Equipped with a large 3.5″ TFT color display, this tester allows for quick and accurate evaluations of electrical installations, ensuring compliance with safety regulations.
It also features a built-in camera function for documentation, SD card storage, and Bluetooth connectivity, making it a versatile tool for electrical safety assessments.
- Specifications and Dimensions
- Display: 3.5″ TFT LCD (320 x 240 pixels)
- Test Voltage Options: 125V, 250V, 500V, 1000V
- Insulation Resistance Measurement: 0 … 1000 MΩ
- Loop Impedance Measurement: L-N, L-PE, N-PE
- Low-Ohm Measurement: 0 … 2000 Ω
- Voltage Measurement: 80 … 500V AC/DC
- Frequency Measurement: 45 … 65 Hz
- Grounding Resistance Measurement: 0 … 2000 Ω
- RCD Test Currents: 10mA, 30mA, 100mA, 300mA, 650mA, 1A
- Power Supply: 8 x 1.5V AA batteries
- Operating Time: Approx. 15 hours
- Measurement Category: CAT III 600V
- Protection Class: IP65 (dust and water-resistant)
- Operating Temperature: 0 … 45°C (32 … 113°F)
- Dimensions: 24.2 x 10.5 x 14.5 cm (9.5 x 4.1 x 5.7 in)
- Weight: 1.56 kg (3.4 lbs)
- Key Features and Benefits
- High-precision insulation tester with selectable test voltages up to 1000V
- Measures loop impedance, grounding resistance, and RCD functionality
- 3.5″ TFT display for clear data visualization in any lighting conditions
- Includes SD card storage and Bluetooth connectivity for easy data transfer
- IP65-rated housing ensures durability in industrial environments
