The Jet TS300-050 3PH 460V 3-Ton Electric Hoist w/ 50′ Lift (144046) is a heavy-duty lifting equipment designed for industrial applications. Built with safety and efficiency in mind, this hoist offers reliable performance and durability.
KEY FEATURES AND BENEFITS:
- Enhanced Safety: Equipped with a dual braking system (mechanical and overload protection) for added security.
- Precise Control: Patented gear limit switch prevents accidental overlifting or lowering.
- Reliable Operation: IP55 TEFC motor with Class F insulation ensures performance in harsh environments.
- Efficient Lifting: Two-speed motor for versatile lifting tasks.
- Durable Construction: 5 Pocket Chain Sprocket reduces vibration and chain wear.
SPECIFICATIONS:
- Capacity: 3 tons (6600 lbs)
- Lift Height: 50 feet
- Motor: 5 HP, 460V, 3 Phase
- Duty Cycle: 40%/20% (H4)
- Lifting Speed: 21/5 FPM
- Weight: 507 lbs
- Headroom: 41-1/3 inches
- Overall Width: 20-7/8 inches
HOW TO USE:
- Inspect: Check the hoist for any visible damage before use.
- Power Supply: Connect the hoist to a reliable 460V, 3-phase power source.
- Load Attachment: Securely attach the load to the hoist hook using appropriate lifting gear.
- Operation: Use the pendant control to raise or lower the load.
- Safety: Always wear appropriate safety gear and follow safety guidelines.
BENEFITS OF USING JET TS300-050 3PH 460V 3-TON ELECTRIC HOIST W/ 50′ LIFT (144046):
- Improves efficiency and productivity in lifting tasks
- Reduces manual labor and risk of injuries
- Handles heavy loads with ease and precision
- Built to last with durable components
- Enhances workplace safety with multiple safety features
FEATURES:
- Dual braking system for enhanced safety
- Patented gear limit switch for precise control
- IP55 TEFC motor for reliable operation in harsh environments
- Two-speed motor for versatile lifting tasks
- 5 Pocket Chain Sprocket for reduced vibration and chain wear
- IP65 rated pendant control for durability
- Built-in heat protection for extended product life
- Includes 10ft power supply cord
