PCE Instruments Gloss Meter (PCE-RM 100) is a precision instrument designed for measuring the reflection properties of surfaces. This device is ideal for applications in furniture design, lighting analysis, and workplace quality control. By evaluating how light reflects off surfaces, the gloss meter helps determine opacity levels with accuracy.
It follows international standards such as ISO3906-1980, ISO3905, and ISO2814, making it a reliable tool in industrial and commercial settings. The compact design, large LC display, and USB connectivity enhance usability, making it easy to integrate into various workflows.
- Specifications and Dimensions
- Measuring Range: 0 to 100 (0 is transparent, 100 is fully opaque)
- Optical Measurement Angle: 45º
- Measurement Accuracy: ±1
- Resolution: 0.1
- Repeatability: ±0.3
- Measuring Surface: 7 x 14 mm (elliptical)
- Interface: USB for data transfer
- Power Supply: 3.7V Li-ion battery
- Operating Conditions: 0 … 40°C / 32 … 104°F, <85% RH
- Dimensions: 141 x 45 x 79 mm / 5.6 x 1.8 x 3.1 in
- Weight: Approximately 310 g / < 1 lb
- Key Features and Benefits
- Accurate measurement of surface opacity and reflectance
- Large LC display for easy readability
- Battery-powered design for portability
- USB interface for data transfer and analysis
- Simple operation with an intuitive user interface
- Supports international measurement standards (ISO3906-1980, ISO3905, ISO2814)
- Ideal for furniture design, lighting assessments, and quality control
- Includes
- 1 x Gloss Meter PCE-RM 100
- 1 x White & Black Standard
- 1 x White & Black Test Box
- 1 x Power Supply
- 1 x Cleaning Cloth
- 1 x Carrying Case
- 1 x Operating Instructions
